A buffer tank is a valuable addition to your heat pump and home heating system. It increases the efficiency, comfort, safety and versatility of the system when heating your home, and also increases the service life of the equipment.
A mismatch between the heat pump's performance and heat demand can result in inefficient operation. The heat pump may turn on and off too frequently, reducing its efficiency and increasing energy consumption. The buffer tank serves as a reservoir for heated water, allowing the heat pump to operate more smoothly and efficiently. The pump can heat water into the tank in large portions and then gradually release the heat to the heating system, which reduces the number of on and off cycles. This increases the service life of the equipment and guarantees uniform, comfortable heating.
![]() |
![]() |
![]() |
![]() |
||
Model | BUF-S80 | BUF-S1OO | BUF-S150 | BUF-S200 | |
---|---|---|---|---|---|
Volume | L | 80 | 100 | 150 | 200 |
Stainless steel inner tank Diameter | mm | φ470 | φ470 | φ470 | φ470 |
Inner tendon material | I | SAF2205 | SAF2205 | SAF2205 | SAF2205 |
Outer tank diameter | mm | φ560 | φ560 | φ560 | φ560 |
Water tank height | mm | 691 | 807 | 1095 | 1383 |
Package connection | mm | 640*640*750 | 640*640*910 | 640*640*1160 | 640*640*1440 |
UnPacked Weight | kg | 20 | 24 | 30 | 35 |
Packed Weight | kg | 23 | 27 | 33 | 40 |
Inlet / outIet connection | inch | G1-1∕4 | G1-1∕4 | G1-1∕4 | G1-1∕4 |
Temp. sensor connection | inch | G-1/2 | G-1/2 | G-1/2 | G-1/2 |
Element heating connection | inch | G1 | G1 | G1 | G1 |
Air vent | inch | G-1/2 | G-1/2 | G-1/2 | G-1/2 |
Drain connection | inch | G-3/4 | G-3/4 | G-3/4 | G-3/4 |
Element heating | kW | 2 | 2 | 2 | 2 |
Magnesium rod | strip | Φ22*350 | Φ22*350 | Φ22*350 | Φ22*350 |
Max. Working Pressure | bar | 6 | 6 | 6 | 6 |
Max. Testing Pressure | bar | 8 | 8 | 8 | 8 |
Max. Testing Temperature | °C | 90 | 90 | 90 | 90 |
![]() |
![]() |
![]() |
![]() |
||
Model | BUF-E60 | BUF-E1OO | BUF-E150 | BUF-E200 | |
---|---|---|---|---|---|
Volume | L | 60 | 100 | 150 | 200 |
Enamel inner tank Diameter | mm | φ370 | φ370 | φ410 | φ410 |
Outer tank diameter | mm | φ460 | φ460 | φ500 | φ500 |
Water tank height | mm | 790 | 1070 | 1302 | 1682 |
Package connection | mm | 535*535*847 | 535*535*1130 | 610*610*1350 | 610*610*1735 |
Inlet / outIet connection | inch | G1 | G5∕4" | G5∕4" | G5∕4" |
UnPacked Weight | kg | 45 | 48 | 51 | 58 |
Packed Weight | kg | 47 | 51 | 54 | 62 |
Temp. sensor connection | inch | G-1/2 | G-1/2 | G-1/2 | G-1/2 |
Element heating connection | inch | G1 | G1 | G1 | G1 |
Air vent | inch | G-1/2 | G-1/2 | G-1/2 | G-1/2 |
Drain connection | inch | G-3/4 | G-3/4 | G-3/4 | G-3/4 |
Element heating | kW | 2 | 2 | 2 | 2 |
Magnesium rod | strip | Φ22*350 | Φ22*350 | Φ22*350 | Φ22*350 |
Max. Working Pressure | bar | 6 | 6 | 6 | 6 |
Max. Testing Pressure | bar | 8 | 8 | 8 | 8 |
Max. Testing Temperature | °C | 90 | 90 | 90 | 90 |
